high-quality die cutting rule

Die cutting rule are also called die cutter or creasing rule; they refer to sheet-like materials made of steel with a blade on the top of the die-cutting plate.

The performance of die cutting rule requires uniform steel texture, proper combination of hardness of blade body and blade, accurate specifications, and quenching of the blade. The edge hardness of high-quality die cutting rule is usually significantly higher than that of the blade body, which not only facilitates forming, but also provides a longer die cutting life. The commonly used thickness of die cutting rule are 0.45mm, 0.53mm, 0.71mm, 1.05mm, 1.42mm and other different specifications. Common heights are 8mm, 9.5mm, 23.8mm, 30mm, 40mm, 50mm and other different heights.

Features of Yitai Die Cutting rule:

1. Select high-quality steel

The molecular structure of steel is tight, the blade body is flexible, there is not much rebound after being bent, and the molecular structure remains tightly connected.

2. Exquisite surface decarburization treatment

The brittle carbon molecules are withdrawn from the surface of the die-cutting rule, so that the blade will not break due to surface brittleness when the blade is bent. It is like a layer of soft skin tissue to wrap the blade, making it easier to bend and shape.

3. Excellent heat treatment

Die-cutting rules can be adjusted to different hardnesses according to different requirements of customers, the blade body can be adjusted to be soft for bending, and the peak of the knife can be adjusted hard to make it durable.

4. Extremely high precision

The higher the precision of the die-cutting rule, the shorter the pressure-regulating time of the die-cutting machine, the lower the mechanical wear, the faster the production speed, and the better the die-cutting effect. Especially the die-cutting of self-adhesive labels, the die-cutting knife without precision is not qualified at all.

5. There are more specifications and models for customers to choose

Yitai die-cutting rules have more specifications and models for customers to choose from. Choosing the most suitable type and specification of die-cutting rules is the key to die-cutting quality assurance.
